Some representative dimensions for cutting non-ferrous metals

Diameter D	Cutting Width ap	Bore b	No of Teeth	Noise Reduced
800	8.5	69.85	42
900	8.0	80	60
1000	7.5	100	120
1100	7.0	110	52
1100	7.0	110	70
1200	8.5	80	60
1250	8.7	100	90
1400	9.0	110	52
1400	9.0	110	70
1430	10.0	100	80
1500	10.5	110	70
1600	10.5	100	72
1750	11.5	150	60
1980	12.5	120	52
1980	12.5	120	72

Some representative dimensions for billet sawing plants

Diameter D	Cutting Width ap	Bore b	No of Teeth	Noise Reduced
610	5.7	80	64
660	6.5	80	80
720	6.5	80	52
830	7	80	64
850	8	80	54
965	8.5	80/100	60
1020	8.5	100	60
1100	8.5	100	74
1250	8.5	80/100	80
1370	10	139.7	60
1430	11	100	60
1520	11	100	86
1730	10	139.7	50
1860	11	100	56
1900	10.5	100	180

Some representative dimensions for tube layer sawing plants

Diameter D	Cutting Width ap	Bore b	No of Teeth	Noise Reduced
830	7	80	80
965	8.5	100	80
1020	6.8	100	136
1250	7.8	100	150
1350	8	80/100	140
1400	8	100	180
1510	11	100	220
1600	10.5	100	140
1600	10.5	150	160
1650	9.5	100	210
1700	10	100	160
1980	11.5	100	190

 Some representative dimensions for ERW lines

Diameter D	Cutting Width ap	Bore b	No of Teeth	Coated
355	3.2	45	52
355	3.2	45	72
380	3.8	115	52
380	3.8	115	64
400	4.3	115	48
450	4.3	115	52

Other dimensions and executions on request

A selection of Multi cut machines for ERW lines

SMS MEER; NAKATA; DALIAN SAGE; ABBEY; PLANTOOL; OTO MILS; LINSINGER

A selection of high performance cold circular sawing machines(for tube layer- and billet cutting)

FRAMAG; MFL; OHLER; MAIR; DALIAN SAGE; LAZZARI; LINSINGER
